- Supports new Alpha Slot B Module
- Uses Alpha Slot B modules with:
- 600 & 700 MHz 21264A
processors
- 2MB or 4MB Cache, 128bit data path
- LW Synchronous SRAMs
(SSRAMs)
- AMD-751 System Controller
- 100MHz System Bus
- 64-bit Memory Bus
- 2x AGP Bus
- Four PCI 32bit/33MHz slots
- Two ISA slots
- Synchronous DRAM (SDRAM) memory
subsystem supporting:
- 64MB to 768MB memory
- 3 PC100 168-pin unbuffered
DIMMs
- ALIs M1543C Southbridge chip
provides the interface to the
peripherals and ISA support
- Ultra DMA IDE (two ports)
- Floppy diskette control
- Two serial ports with modem
control
- Parallel port
- PS/2 keyboard and mouse
- Dual USB ports
- 2MB of flash ROM
- ATX form factor 12"x9.6"
- Linux for Alpha (including most major distributions)
- Three Year Limited Warranty
- UP1000 Quick Start Guide
- UP1000 Motherboard
Users Manual
| Characteristic |
Specification
|
| Operating temperature range |
5°C to 35°C (41°F to 95°F) |
| Storage temperature range |
-35°C to 85°C (-31°F to 185°F) |
| Size |
30.48cm x 24.38cm (12in x 9.6in) |
| Power Requirements |
400W ATX Power
Supply |
| +5V 24-30A +12V 14A +3.3V 20-28A |
 |
| -5V 1.0A -12V 1A + 5Vsb 850ma |
|
| +5V and +3.3V Total Max 215W |
|
|
